S.M.S.L VMV

SMSL D10 2*CS43131 3.5mm 4.4mm Portable USB Headphone Amplifier DAC

SMSL D10 2*CS43131 3.5mm 4.4mm Portable USB Headphone Amplifier DAC

Regular price $69.99 USD
Regular price $69.99 USD Sale price $69.99 USD
Sale Sold out
Color
Ships From

SMSL D10 Portable USB Headphone Amplifier Audio DAC

Overview

The SMSL D10 is a high-performance portable USB headphone amplifier and audio DAC featuring dual Cirrus Logic CS43131 chips. It offers superb sound quality with support for DSD256 hard decoding and PCM 32bit/384kHz hi-res audio, making it an excellent choice for audiophiles seeking high-fidelity sound on the go.

Features

  • Dual CS43131 DAC Chips: Equipped with two Cirrus Logic CS43131 DAC chips for pure and high-quality audio reproduction.
  • Support for High-Resolution Audio: Supports DSD256 hard decoding and PCM 32bit/384kHz to achieve highly accurate sound reproduction.
  • 3.5mm and 4.4mm Balanced Outputs: Features both 3.5mm headphone jack and 4.4mm balanced headphone jack, providing versatility and compatibility with various headphones.
  • High Output Power: The headphone amplifier delivers up to 500mW @ 16Ω, suitable for most headphones.
  • Minimalistic and Transparent Design: The transparent window and textured aluminum housing allow visibility of the internal components, adding to its aesthetic appeal.
  • Convenient Side Volume Button: Easy to operate and control volume levels.
  • Versatile Usage Scenarios: Can be connected to computers, phones, and other devices via USB for high-quality audio output.

Specifications

  • DAC Chip: 2x CS43131
  • Headphone Interface: 3.5mm single-ended, 4.4mm balanced
  • SNR: 121dB
  • Dynamic Range: 121dB
  • Maximum Output Power: 500mW @ 16Ω, 500mW @ 32Ω, 160mW @ 150Ω, 80mW @ 300Ω, 40mW @ 600Ω
  • THD+N: 0.00015% (116dB)
  • Sampling Rate USB: PCM 44.1~384kHz, DSD 2.8224~11.2896MHz
  • Bit Depth USB: 1bit, 24~32bit
  • Power: 5V/200mA
  • Size: 55 x 11 x 20mm (WxHxD)
  • Weight: 17.5g
  • USB Compatibility: Windows 7/8/8.1/10/11 (Needs Driver), Mac OSX 10.6+, Linux, Android, iOS

Product Details

The SMSL D10 is designed for audiophiles who demand high-quality sound on the go. Its compact size and lightweight build make it easy to carry, while its powerful output ensures that it can drive a wide range of headphones. The dual CS43131 DAC chips deliver crystal-clear audio with minimal distortion, and the support for high-resolution audio formats means you'll hear every detail in your music.

The device's minimalistic design is both stylish and functional, with a transparent window that showcases its high-quality components. The side-mounted volume button allows for easy adjustments, and the multiple output options provide flexibility for different listening setups.
